C175, C176, C177 SPEED VAR. Inputs
C175
C176
C177
Range
0 ÷ 16
0 ÷
24 if ES847 or ES870 is
fitted
0 → Inactive
1 ÷ 8 → MDI1 ÷ MDI8
9 ÷ 12 → MPL1 ÷ MPL4
13 ÷ 16 → TFL1 ÷ TFL4
17 ÷ 24 → XMDI1 ÷ XMDI8
Default
0
Inactive
Level
ENGINEERING
Address
1175, 1176, 1177
Function
This function generates up to 7 values of variation % for the active reference ranging
from –100% to 100% with parameters P115÷P121.
The 3 functions determine which of the 7 values of the speed reference variation is
active: the active value (1) or inactive value (0
) of each preset input signal determines a
bit-logic binary number where SPEED VAR. 0 is the least
significant bit (bit 0), while
SPEED VAR. 2 is the most significant bit (bit 3) as shown in Table 105 and Table 106.
If one of these functions is not set up, its bit is “zero”.
Table 105: Selection of the speed reference variation
Variation of the Selected Speed
Reference =
Bit 2
Bit 1
Bit 0
SPEED
VARIATION 2
SPEED
VARIATION 1
SPEED VARIATION
0
Table 106: Variation of the selected speed reference
Function:
Input Status
MULTISPEED 0
0
1
0
1
0
1
0
1
MULTISPEED 1
0
0
1
1
0
0
1
1
MULTISPEED 2
0
0
0
0
1
1
1
1
Variation of the
selected speed
reference
None 1 2 3 4 5 6 7
Variation %
selected
0 P115 P116 P117 P118 P119 P120 P121
If one of the functions above is not set up, its bit is “zero”.
For example, if C175 and C177 are INACTIVE (0) and C176 is programmed for one terminal, only variation 2
corresponding to parameter P116 can be selected.
In any case, the output speed must never exceed the max. allowable speed, even when a higher speed is required.
NOTE
In Table 106 above:
0 ⇒ Inactive Input;
1 ⇒ Active Input.
