8.4. Digital Inputs Menu
This menu allows checking the state of the command sources for the digital inputs (local terminals, serial link and
fieldbus), the terminal board resulting from their combination and the terminals which are actually used for the drive
control. The terminals which are actually used to control the drive also consider any timers applied to the digital inputs.
M031 Delayed Digital Inputs
M031
Range
Bit-controlled measure
See Table 1
Active
Always active.
Address
1681
Function
Status of the control terminal board used by the drive.
This is the terminal board resulting from the combinati
on of the preset command sources
(local terminal board, serial link and fieldbus), where:
- Inputs MDI1 to MDI8 are the result of the OR between the different control sources.
- The ENABLE (E) status is the result of the AND of inputs MDI2&S of the physical
terminals
and of MDI2 inputs of all the other programmed control sources.
- The ENABLE SW (ESW) is the result of the AND of the inputs programmed as
ENABLE
SW (C152) of all the programmed command sources.
See also the CONTROL METHOD MENU and the TIMERS MENU.
Refer to Figure 54 for the ENABLE and ENABLE SW status.
M032 Instant Digital Inputs
M032
Range
Bit-controlled measure
See Table 1
Active
Always active.
Address
1682
Function
Status of the virtual control terminal board upstream of the application of the timers to the
digital inputs (if no timer is applied, it matches with M031).
See the CONTROL METHOD MENU and the TIMERS MENU.
Refer to Figure 53 for the ENABLE and ENABLE SW status.
Table 1: Coding of Measures M031, M032
Bit n.
Digital Input
Bit n.
Digital Input
0
MDI1
5
MDI6/ECHA/FINA
1
MDI2(ENABLE)
6
MDI7/ECHB
2
MDI3(RESET)
7
MDI8/FINB
3
MDI4
8
ENABLE-SW
4
MDI5
9
ENABLE
M033 Local Control Terminal Board
M033 Range Bit-controlled measure See Table 3
Active
Always active.
Address
1683
Function
Status of the digital inputs in the drive physical terminal board.
The status of MDI2&S (S) input is the result of a logic AND between ENABLE-A
and
ENABLE-B physical signals.
Table 2: Coding of Measures M033
Bit n.
Digital Input
Bit n.
Digital Input
0
MDI1(START)
4
MDI5
1
MDI2&S (S)
5
MDI6/ECHA/FINA
2
MDI3(RESET)
6
MDI7/ECHB
3
MDI4
7
MDI8/FINB
