Santerno Sinus Penta - PID Regulator Menu

SINUS PENTA
PROGRAMMING GUIDE
56/486
8.3. PID Regulator Menu
This menu contains the measures relating to the input and output values of the internal PID regulator.
M018 PID Reference at Constant RPM (%)
M018 Range
±10000
±100.00 %
Note
: The actual range depends on the max. value and the min. value of
the PID reference set in parameters P245–P246.
Active
Always active.
Address
1668
Function
This is the measure of the PID reference expressed as a percentage. Scaling
is detailed in
the PID PARAMETERS MENU and the PID CONFIGURATION MENU.
M018a PID2 Reference at Constant RPM (%)
M018a Range
±10000
±100.00 %
Note:
The actual range depends on the max. value and the min. value
of the PID2 reference set in parameters P445-P446.
Active
This measure is active if enabled from C291a
Address
1731
Function
This is the measure percent of the reference selected with C286 for the PID2 or the 2-zone
mode. Scaling is detailed in the PID2 PARAMETERS MENU and the
PID CONFIGURATION
MENU.
M019 PID Reference after Ramps (%)
M019 Range
±10000
±100.00 %
Note
: The actual range depends on the max. value and the min. value of
the PID reference set in parameters P245–P246.
Active
Always active.
Address
1669
Function
This is the measure of the PID reference after the ramps expressed as a percentage.
Scaling
is detailed in the PID PARAMETERS MENU and the PID CONFIGURATION MENU.
M019a PID2 Reference after Ramps (%)
M019a Range
±10000
±100.00 %
Note:
The actual range depends on the max. value and the min. value
of the PID2 reference set in parameters P445-P446.
Active
This measure is active if enabled from C291a
Address
1732
Function
This is the measure percent of the current PID reference after the ramps selected with C286
for the PID2 or the 2-zone mode. Scaling is detailed in the PID2 PARAMETERS MENU
and the
PID CONFIGURATION MENU.
M020 PID Feedback (%)
M020 Range
±10000
±100.00 %
Note
: The actual range depends on the max. value and the min. value of
the PID feedback set in parameters P247–P248.
Active
Always active.
Address
1670
Function
This is the measure of the PID feedback expressed as a percentage.
Scaling is detailed in the
PID PARAMETERS MENU and the PID CONFIGURATION MENU..
