Santerno Sinus Penta - Table 21: Preset PID Units of Measure

PROGRAMMING GUIDE
SINUS PENTA
89/486
Table 21: Preset PID units of measure
Unit of
Measure
P267/P267b
Item
Displayed
Unit of
measure
P267/P267b
Item
Displayed
Customized
0: Disabled
----(see P267a)
m
18: m
m
bar
1: bar
bar
ft
19: ft
ft
mbar
2: mbar
mbar
m/s
20: m/s
m/s
atm
3:atm
atm
ft/s
21: ft/s
ft/s
Pa
4: Pa
Pa
rpm
22: rpm
rpm
kPa
5: kPa
kPa
gal/s
23: GPS
GPS
PSI
6: PSI
PSI
gal/min
24: GPM
GPM
m
3
/s
7: m3/s
m3/s
gal/h
25: GPH
GPH
m
3
/min
8: m3/m
m3/m
ft
3
/s
26: CFS
CFS
m
3
/h
9: m3/h
m3/h
ft
3
/min
27: CFM
CFM
l/s
10: l/s
l/s
ft
3
/h
28: CFH
CFH
l/min
11: l/m
l/m
A
29: A
A
l/h
12: l/h
l/h
V
30: V
V
°
13: °
°
W
31: W
W
°C
14: °C
°C
kW
32: kW
kW
°F
15: °F
°F
HP
33: HP
HP
Nm
16: Nm
Nm
CV
34: CV
CV
kgm
17: kgm
kgm
P267a/P267c Custom PID/PID2 Units of Measure
P267a Range
0x20 ÷ 0x8A (every byte)
ASCII 0x20 = blank
ASCII 0x8A = 
Default
0x015D255B
ASCII 0x5D = [
ASCII 0x25 = %
ASCII 0x5B = ]
⇒ [%]
Level
ENGINEERING
Address
1867/1869
(This is a 32-bit data item)
Characters are 8-bit ASCII encoded; there are three 8-
bit characters starting from the least
significant bit. Bit
24 must always be set to 1.
Function
Parameter P267a/P267c is active only if P267/P267b = 0: [Disable] and it relates to
the unit of measure actually displayed in M023, M024, M023a, M024a
. This
parameter allows setting a 3-
character string to display the units of measures for the
PID Measures: M023, M024, M023a, M024a.
Press the SAVE/ENTER
key to edit each character: when a flashing cursor appears
on the left of each character, press ▲ and ▼
to scroll all the characters displayed.
Press the ESC key to go to the next character. Press SAVE/ENTER
to store the new
parameter value.
NOTE See also parameter P257/P457 in the PID PARAMETERS MENU.
