33.1.3. MAXIMUM PROGRAMMABLE SPEED VALUE
The maximum preset carrier frequency value also limits the maximum speed value to be programmed:
Max. programmable speed
→
rated speed * (maximum output frequency/rated frequency)
where the maximum output frequency results from the following:
C002
≤
5000Hz fout_max = C002 / 10
5000Hz < C002
≤
8000Hz fout_max = 500
8000Hz < C002 fout_max = C002 / 16
C002 is the maximum carrier frequency and the divisor is the min. allowable number of pulses per period.
Table 70: Maximum value of the output frequency depending on the Penta model
Model
Max. output frequency
(Hz) (*)
2T/4T
0005 to 0014
599 (**)
0015 to 0129
599 (***)
0150 to 0402
500
0457 to 2076
400 (****)
(**) 1000Hz on demand, except for models 0008, 0010 and 0013 (625Hz on demand)
(***) 625Hz on demand, except for models 0040 (1000Hz on demand) and 0049 (800Hz on demand)
(****) 500Hz for models 0523, 0599, 0749, 0832, 0850, 0965 and 1129
Model
Max. Output
Frequency (Hz) (*)
5T/6T
0003 to 0069
500
0076 to 0600
400
0748 to 2076
200 (*****)
(*****) 400Hz for models 0750, 0828, 0960 and 1128
(*) NOTE
The maximum output frequency is limited to the speed level programmed in parameters C028,
C029 [–32000 ÷ 32000]rpm. This results in Fout
max
= (RPM
max
*NPole)/120.
EXAMPLE:
When using a 4-pole motor and 30,000rpm are required, F
out
will be 1000Hz, so the performance requirements are
fulfilled.
On the other hand, if the same performance requirements are needed with an 8-pole system, 30,000rpm cannot be
obtained, as F
out
is 2000Hz. As a result, when using an 8-pole motor, the maximum allowable programmable speed is
15,000rpm[RPM
outmax
=(F
outmax
*120)/(number of motor poles)].
