PROGRAMMING GUIDE
SINUS PENTA
13/486
NOTE
In order to install your application SW and update the firmware packages of the SINUS
PENTA drive, you can use the Remote Drive software provided by Elettronica Santerno.
Please refer to the Remote Drive DRIVE REMOTE CONTROL – User Manual for detailed
instructions.
Any detail concerning optional functionality is given in separate manuals covering SINUS PENTA’s optional applications.
0.5.3. MENUS AND SUBMENUS
This User Manual (Programming Guide) is divided into different Menus. Their sequence is the same as their
display sequence in the display/keypad and the RemoteDrive software.
Programming parameters and Measure parameters are divided into:
Mxxx Measures (always Read Only):
Mxxx Range
Drive representation
(integer)
Display on the display/keypad and the
RemoteDrive
(may be a decimal figure)
plus unit of measure
Active
Type of control (IFD / VTC / FOC) the measure is related to
Address
Modbus address which the measure can be read from
(integer)
Function
Measure description
Pxxx Parameters (always R/W):
Pxxx Range
Drive representation
(integer)
Display on the display/keypad and the
RemoteDrive
(may be a decimal figure)
plus unit of measure
Default
Factory-setting of the parameter
(as represented for the drive)
Factory-setting of the parameter
(as displayed)
plus unit of measure
Level
User level (BASIC / ADVANCED / ENGINEERING)
Address
Modbus address which the parameter can be read from
(integer)
Control
This optional field is displayed when a parameter is not active for all types of
motor controls (IFD / VTC / FOC)
Function Parameter description
