58.4. List of the DRIVECOM Alarm Codes
If a PROFIdrive expansion board is used (see PROFIDRIVE BOARD CONFIGURATION MENU), the Sinus Penta fault
codes are also coded according to the DRIVECOM communication profile.
The specific code is readable @ address 947 of the specific PROFIDRIVE PARAMETERS (see PROFIdrive
COMMUNICATIONS BOARD USER MANUAL).
The DRIVECOM User Group e.V. is an association of international drive manufacturers, universities, and institutes
. It
has set itself a goal to develop a simple integration of drives in open automation systems. The DRIVECOM User Group
therefore decided to standardise the communication interface for accessing drives.
Also visit www.drivecom.org
.
Table 137: List of the DRIVECOM alarm codes
Code
Meaning
Sinus Penta Fault
#
0000
No malfunction
–
A000
1000
General malfunction
NoCurrent Fault
A060
AutoTune Fault
A065
No Output Phase
A129
2000
Current
2300
Current on device output side
2310
Continuous overcurrent
2311
Continuous overcurrent No. 1
SW OverCurrent
A044
2312
Continuous overcurrent No. 2
PWMA1 Fault
A051
2320
Short circuit / earth leakage
PWMA Fault
A041
PWMA0 Fault
A050
PWMA Not ON
A053
3000
Voltage
3100
Mains voltage
3130
Phase failure
Mains Loss
A064
3200
Internal voltage
3210
Internal overvoltage
OverVoltage
A048
3220
Internal undervoltage
UnderVoltage
A047
4000
Temperature
PT100 Channel 1 Fault
A105
PT100 Channel 2 Fault
A106
PT100 Channel 3 Fault
A107
PT100 Channel 4 Fault
A108
4100
Ambient
4110
Excess ambient temperature
Amb.Overtemp.
A109
4300
Drive temperature
4310
Excess drive temperature
Drive OverHeated
A074
HeatSink Overheated
A094
5000
Device hardware
5111
U1 = supply +/- 15 V
±15V Loss
A087
5200
Control
Torque Off Not Safe
A140
5210
Measurement control
ADC Not Tuned
A088
5220
Computing circuit
5300
Operating unit
Parm Lost Chk
A072
Parm Lost COM1
A073
MMI Trouble
A078
KeyPad WatchDog
A081
Parm Lost COM2
A089
Parm Lost COM3
A090
5400
Power section
Fan Fault
A096
2nd Sensor Fault
A099
5440
Contactors
5441
Contactor 1 = manufacturer specific
Bypass Circuit Fault
A045
5442
Contactor 2 = manufacturer specific
Bypass Connector Fault
A046
5443
Contactor 3 = manufacturer specific
Bypass Circuit Open
A093
5500
Data storage
5510
RAM
RAM Fault
A049
