SINUS PENTA
PROGRAMMING GUIDE
84/486
11. DISPLAY/KEYPAD MENU
11.1. Overview
NOTE
It is recommended that the “Operating and Remoting the Keypad” section in the Motor
Drives Accessories – User Manual be read as well.
The Display/Keypad Menu contains programming parameters to do the following:
Set the navigation mode within the drive menus;
Select the Root Page;
Select measures from the Root Page and the Keypad Page;
Select the type of Keypad Page displayed in Local mode;
Set custom PID units of measure;
Disable the LOC/REM or FWD/REV keys in the keypad.
The Root Page, the Keypad Page and Local mode are detailed in the following sections.
11.2. Root Page
I
N
V
E
R
T
E
R
O
K
→
+
1
5
0
0
.
0
0
r
p
m
→
+
0
.
0
0
r
p
m
M
E
A
P
A
R
C
F
[
I
D
P
]
The Root page is factory-set as the startup page to be displayed when the drive is turned on.
NOTE
You can access the four main menus only from the root page:
MEA → Measures;
PAR → Programming parameters;
CF → Configuration parameters;
IDP → Product identification.
Line 1 on this page displays the drive operating status (see the description of parameter M089).
Lines 2 and 3 display two measures which may be selected with parameters P268, P268a. These measures can
be scaled through parameters P268y and P268z.
Line 4 displays the four main menus of the drive. The selected menu is displayed in square brackets: use the ▲ and ▼
keys to select a different menu. Press the SAVE/ENTER key to access the selected menu.
