Santerno Sinus Penta - Table 9: Data Logger Connection Status

PROGRAMMING GUIDE
SINUS PENTA
71/486
M101 Connection Status
M101
Range
Bit-controlled measure
See Table 9
Active
This measure is active only if programmed from parameter R021.
Address
1338
Function
Status of the connections supported by ES851. Note that the COM1 serial link is RS232 by
default, whereas COM 2 is RS485 by default.
For more details, please refer to the Programming Guide manual for the Data Logger
ES851.
Table 9: Data Logger connection status
Bit n.
Connection
Description
0-7
Type of modem connection failure
0: None
1: Dial KO
2: Connect KO
3: Authentication KO
4: IPCP KO*
5: Modem not yet initialized
6: Modem init KO
7: Modem not configured
8: Modem not dial out
16: Connect end (echo time out)
32: Connect end (idle time out)
64: Connect end (term expired)
8-10
Status of the connection via modem
0: No conn.
1: Dialing
2: Connecting
4: Connected
5: Attempt finished
11
COM1
0: No data exchange
1: Data exchanged
12
COM2
0: No data exchange
1: Data exchanged
13
Ethernet
0: No connection
1: Connection
14-15
Reserved
* In computer networking, the Internet Protocol Control Protocol (IPCP) is a network control protocol for establishing
and configuring Internet Protocol over a Point-to-Point Protocol link. The IPCP configures, enables, and disables the IP
protocol modules on both ends of the point-to-point link.
