The following formula can be applied:
LRC x LRT
IEC Class = -------------
FLC x 6
Once the approximated IEC class has been calculated, use the motor thermal time constant (C267) that corresponds to
the closest IEC class from
above.
Example 1a: the 7.5kW motor in the table below can be approximated to have a trip class of:
820 x 20
IEC Class = ------------- = 27.3
100 x 6
The motor thermal time constant that you would select is IEC class 30, C267 = 1080s.
NOTE
A
s an even quicker guide, the IEC trip class can generally be approximated as the
locked rotor time.
Table 119: Typical datasheet for 4-pole, 50Hz-400V motors
Output [kW] IEC Frame
Locked Rotor
Current -
LRC
[% FLC]
Full Load
Current - FLC
[A]
Locked Rotor
Time (cold) -
LRT [s]
Rated speed
[rpm]
0.12
63
450
0.41
44
1415
0.18
63
460
0.58
59
1400
0.25
71
500
0.7
106
1400
0.37
71
500
1.03
81
1395
0.55
80
600
1.3
37
1430
0.75
80
570
1.61
35
1420
1.1
90S
700
2.37
31
1445
1.5
90L
750
3.28
22
1450
2.2
112M
720
4.42
55
1455
4
112M
660
7.85
26
1445
5.5
132S/M
850
10.34
26
1465
7.5
132S/M
820
14
20
1465
Example 1a/1b
9.2
160M
560
17.4
59
1460
11
160M
600
20.84
42
1465
15
160L
650
28.4
37
1465
18.5
180M/L
800
34.83
26
1470
22
180L
790
39.4
35
1475
30
200L
700
55.6
40
1475
37
225S/M
720
65.2
35
1480
45
225S/M
740
78.11
33
1480
55
250S/M
720
95.2
37
1480
75
250S/M
750
131.25
35
1480
90
280S/M
780
154.41
55
1485
110
315S/M
760
189
64
1485
132
315S/M
780
225.53
55
1485
150
315S/M
750
260
44
1485
160
315S/M
760
277
44
1485
185
355M/L
720
320
117
1490
200
355M/L
660
342
108
1490
220
355M/L
700
375
84
1490
250
355M/L
690
425
79
1490
Example 2
260
355M/L
650
445
90
1490
280
355M/L
710
471
86
1490
300
355M/L
670
504
103
1490
315
355M/L
670
529
92
1490
330
355M/L
650
554
70
1490
