SINUS PENTA
PROGRAMMING GUIDE
12/486
0.4. Scope of this Manual
Elettronica Santerno is committed to update its User Manuals available for download from santerno.com
with the latest
software version officially released. Please contact Elettronica Santerno if you require technical documents related to
previous software versions.
0.5. How to Use this Manual
0.5.1. OVERVIEW
This User Manual (Programming Guide) provides any information required to setup and monitor the drives of the Sinus
Penta series manufactured by Elettronica Santerno SpA.
Setup/monitoring may be obtained using one of the following options:
• Display/keypad unit;
• Serial link through RS485 standard port or ES822 (isolated optional serial board) RS485/RS232;
• ES851 (optional Data Logger and communications board).
For the instructions on how to use and remote the display/keypad unit, please refer to the Installation Guide and the
Motor Drives Accessories – User Manual.
Any information sent to/from the drive via the display/keypad unit may be obtained also
via serial link using the RemoteDrive software application offered by Elettronica Santerno.
RemoteDrive allows the following functions: image acquisition, keypad simulation,
oscilloscope functions and multifunction tester, data logger, table compiler including
history data, parameter setup and data reception-transmission-storage from and to a
calculator, scan function for the automatic detection of the connected drives (up to 247
drives may be connected).
You can also create your own dedicated software via serial communication link. This manual provides any information
concerning addressing (Address field) and scaling (Range field) for the drive interfacing.
0.5.2. SPECIAL APPLICATIONS DEDICATED TO SINUS PENTA
DRIVES
Special software is supplied with the drives of the Sinus Penta series, that can be used for particular applications. The
menu tree, the programming mode and navigation mode of the Sinus Penta are used; parameters or menus will be
added/(removed) whether required/(not required) for the implemented application.
The dedicated applications implement the most common automation applications, thus replacing PLCs or dedicated
control boards, and they reduce to a minimum the electric equipment required, thus ensuring lower maintenance costs.
Such operating modes can be implemented through the firmware updating and/or through additional interface boards.
The following applications are currently available:
Identifier Application
PD
Sinus Penta Drive (Asynchronous Motor control)
PR
Regenerative Sinus Penta – (see Guide to the
Regenerative Application)
PS
Sinus Penta – Synchronous Motor Control (see Guide to
the Synchronous Motor Application)
