26.3. Examples
This section illustrates some examples.
A table stating the setup of the parameters used is given for each example.
Parameters highlighted in grey have no effect due to their preset selection.
Example 1: Digital output for Inverter Alarm digital command (MDO3 digital output default setting).
Table 50: MDO parameterization for PD Status OK
P288
MDO3: Digital output mode
DIGITAL
P289
MDO3: Variable A selection
D3: Inverter Alarm
P290
MDO3: Variable B selection
P291
MDO3: Testing variable A
P292
MDO3: Testing variable B
P293
MDO3: Comparing value for Test A
P294
MDO3: Comparing value for Test B
P295
MDO3: Function applied to the result of the two tests
P295a
MDO3: Variable C selection
D0: Disabled
P295b
MDO3: Function applied to the result of f(A,B) and C test
P296
MDO3: Output logic level
FALSE
The digital output status depends on the Boolean variable “Inverter Alarm”, which is TRUE only when an alarm trips.
This output is a fail-safe contact: the relay energizes if the drive is on and no alarms tripped.
Example 2: Digital output for Drive Run OK digital command (MDO4 digital output default setting).
Table 51: MDO parameterization for drive Run OK
P297
MDO4: Digital output mode
DIGITAL
P298
MDO4: Variable A selection
D1: Drive Run Ok
P299
MDO4: Variable B selection
P300
MDO4: Testing variable A
P301
MDO4: Testing variable B
P302
MDO4: Comparing value for Test A
P303
MDO4: Comparing value for Test B
P304
MDO4: Function applied to the result of the two tests
P295a
MDO3: Variable C selection
D0: Disabled
P295b
MDO3: Function applied to the result of f(A,B) and C test
P305
MDO4: Output logic level
TRUE
The digital output status depends on the Boolean variable “Drive Run Ok”, which is TRUE only when the drive is
modulating (IGBTs on).
