PROGRAMMING GUIDE
SINUS PENTA
349/486
C188a, C188b, C188c Inputs for PID MULTIREFERENCES
C188a
C188b
C188c
Range
0 ÷ 16
0 ÷
24 if ES847 or ES870 is
fitted
0 → Inactive
1 ÷ 8 → MDI1 ÷ MDI8
9 ÷ 12 → MPL1 ÷ MPL4
13 ÷ 16 → TFL1 ÷ TFL4
17 ÷ 24 → XMDI1 ÷ XMDI8
Default
0
Inactive
Level
ADVANCED
Address
1365, 1366, 1367
Function
This function allows generating up to 7 PID references that can be programmed with
parameters P081a to P087a according to the operating mode selected with P080a.
The 3 fun
ctions determine which is the active reference among the 7 available PID
references: the active value (1) or the inactive value (0)
of each programmed input signal
determines a bit-logic value, where MULTIREF 0 is the least significant bit (bit 0)
and
MULTIREF 2 is the most significant bit (bit 2).
If one of the available functions is not programmed, the value of the relevant bit is “zero”.
Table 109: Selection of PID Multireferences
Multireference selected =
Bit 2 Bit 1 Bit 0
MULTIRFERENCE 2 MULTIRFERENCE 1 MULTIRFERENCE 0
