M034 Control Terminals from Serial Link
M034 Range Bit-controlled measure See Table 3
Active
Always active.
Address
1684
Function Status of the digital inputs in the terminal board controlled via serial link.
M035 Control Terminal Board from Fieldbus
M035 Range
Bit-controlled measure See Table 3
Active
Always active.
Address
1685
Function State of the digital inputs in the terminal board controlled via fieldbus.
Table 3: Coding of Measures M034, M035
Bit n.
Digital Input
Bit n.
Digital Input
0
MDI1
4
MDI5
1
MDI2
5
MDI6/ECHA/FINA
2
MDI3(RESET)
6
MDI7/ECHB
3
MDI4
7
MDI8/FINB
M036 Auxiliary Digital Inputs in the Terminal Board
M036
Range
Bit-controlled measure
See Table 4
Active
Always active.
Address
1686
Function
Status of the auxiliary digital inputs in ES847 or ES870 terminal board.
M036a Auxiliary Digital Inputs via Serial Link
M036a
Range
Bit-controlled measure
See Table 4
Active
Always active.
Address
1713
Function
Status of the auxiliary digital inputs via serial link.
M036b Auxiliary Digital Inputs via PROFIdrive
M036b
Range
Bit-controlled measure
See Table 4
Active
Always active.
Address
1717
Function
Status of the auxiliary digital inputs via PROFIdrive.
Table 4: Coding of Measures M036, M036a, M036b
Bit n.
Digital Input
Bit n.
Digital Input
0
XMDI1
4
XMDI5
1
XMDI2
5
XMDI6
2
XMDI3
6
XMDI7
3
XMDI4
7
XMDI8
