Santerno Sinus Penta - List of Parameters P176 to P215

PROGRAMMING GUIDE
SINUS PENTA
155/486
22.3. List of Parameters P176 to P215
Table 42: List of parameters P176 to P215
Param. Function User Level
DEFAULT
VALUES
Modbus
Address
P176
AO1 analog output
ADVANCED
1: ± 10V
776
P177
Selected variable for AO1 analog output
ADVANCED
1: Motor speed
777
P178
Min. value of AO1 selected variable
ADVANCED
–1500 rpm
778
P179
Max. value of AO1 selected variable
ADVANCED
+1500 rpm
779
P180
AO1 Analog output offset
ADVANCED
0.000 V
780
P181
Filter for AO1 analog output
ADVANCED
0 ms
781
P182
Min. AO1 output value with reference to P178
ADVANCED
–10.0 V
782
P183
Max. AO1 output value with reference to P179
ADVANCED
+10.0V
783
P184
AO2 analog output
ADVANCED
1: ± 10V
784
P185
Selected variable for AO2 analog output
ADVANCED
2: Speed reference at
constant rpm
785
P186
Min. value of AO2 selected variable
ADVANCED
–1500 rpm
786
P187
Max. value of AO2 selected variable
ADVANCED
+1500 rpm
787
P188
AO2 Analog output offset
ADVANCED
0.000 V
788
P189
Filter for AO2 analog output
ADVANCED
0 ms
789
P190
Min. AO2 output value with reference to P186
ADVANCED
–10.0 V
790
P191
Max. AO2 output value with reference to P187
ADVANCED
+10.0V
791
P192
AO3 analog output
ADVANCED
2: 0÷10V
792
P193
Selected variable for AO3 analog output
ADVANCED
5: Output current
793
P194
Min. value of AO3 selected variable
ADVANCED
0 A
794
P195
Max. value of AO3 selected variable
ADVANCED
Inverter Imax
795
P196
AO3 Analog output offset
ADVANCED
0.000 V
796
P197
Filter for AO3 analog output
ADVANCED
0 ms
797
P198
Min. AO3 output value with reference to P194
ADVANCED
0.0 V
798
P199
Max. AO3 output value with reference to P195
ADVANCED
+10.0V
799
P200
FOUT output in [MDO1] frequency
ADVANCED
0: Disabled
800
P201
Selected variable for FOUT frequency output
ADVANCED
1: Motor speed
801
P202
Min. FOUT value of selected variable
ADVANCED
0
802
P203
Max. FOUT value of selected variable
ADVANCED
0
803
P204
Min. FOUT output value with reference to P202
ADVANCED
10.00 kHz
804
P205
Max. FOUT output value with reference to P203
ADVANCED
100.00 kHz
805
P206
Filter for FOUT frequency output
ADVANCED
0 ms
806
P207
AO1: Gain
ADVANCED
RESERVED
807
P208
AO2: Gain
ADVANCED
808
P209
AO3: Gain
ADVANCED
809
P210
AO1: Variable MODBUS address
ADVANCED
810
P211
AO2: Variable MODBUS address
ADVANCED
811
P212
AO3: Variable MODBUS address
ADVANCED
812
P213
Amplitude of sinusoidal analog output signal
ENGINEERING
100.0%
813
P214
Frequency of sinusoidal analog output signal
ENGINEERING
1.00 Hz
814
P215
Frequency of saw wave analog output signal
ENGINEERING
1.00 Hz
815
