P176 AO1Analog Output
P176 Range
0 ÷ 7
0: Disabled,
1: ± 10V,
2: 0 ÷ 10V,
3: 0 ÷ 20mA,
4: 4 ÷ 20mA,
5: ABS 0 ÷ 10V,
6: ABS 0 ÷ 20mA,
7: ABS 4 ÷ 20mA.
Default
1
1: ± 10V
Level
ADVANCED
Address
776
Function
Selects the operating mode of AO1analog output.
P
1
7
6
T
y
p
e
o
f
O
u
t
p
u
t
S
i
g
n
a
l
A
O
1
S
W
2
-
1
-
2
→
0
-
2
0
m
A


In the example above, A01 is set as a current input. Contact 1 of SW2 dip-switch is open, contact 2 is closed.
NOTE
Analog outputs are set as volta
ge outputs by default. To set them as current outputs, see
the DIP-switch configuration and follow the instructions displayed on the keypad, or refer to
the Sinus Penta’s
Installation Guide.
P177 Selected Variable for AO1 Analog Output
P177
Range
0 ÷ 69
See Table 36
Default
1
Motor speed
Level
ADVANCED
Address
777
Function
Selects the variable to be allocated to AO1 digital output.
P178 Min. value of AO1 Selected Variable
P178 Range
-32000 ÷ +32000
Depending on the value selected
in P177
- 320.00% ÷ + 320.00 % of the full-scale
value
See Table 36
Default
–1500
–15.00% of 10000 rpm = –1500 rpm
Level
ADVANCED
Address
778
Function
Minimum value of the variable selected via P177, corresponding to the min.
output value of AO1 set in P182.
