PROGRAMMING GUIDE
SINUS PENTA
157/486
P179 Max. value of AO1 Selected Variable
P179 Range
-32000 ÷ +32000
Depending on the value
selected in P177
- 320.00% ÷ + 320.00 % of the full-scale value
See Table 36
Default
+1500
+15.00% of 10000 rpm = +1500 rpm
Level
ADVANCED
Address
779
Function
Maximum value of the variable selected via P177, corresponding to the max.
output value of AO1 set in P183.
P180 AO1 Analog Output Offset
P180 Range
–9999 ÷ +9999
Depending on the value
selected in P176
–9.999 ÷ +9.999
Default
0
0.000 V
Level
ADVANCED
Address
780
Function
Offset value applied to AO1 analog output.
P181 Filter for AO1 Analog Output
P181
Range
0 ÷ 65000
0.000 ÷ 65.000 sec.
Default
0
0.000 sec.
Level
ADVANCED
Address
781
Function
Value of the filter time constant applied to AO1 analog output.
P182 Min. AO1 Output Value with Reference to P178
P182 Range
–100 ÷ +100
–200 ÷ +200
Depending on the value
selected in P176
–10.0 ÷ +10.0 V
–20.0 ÷ +20.0 mA
Default
–100
–10.0 V
Level
ADVANCED
Address
782
Function
Minimum output value obtained when the minimum value of the variable set
in P178 is implemented.
P183 Max. AO2 Output Value with Reference to P179
P183 Range
–100 ÷ +100
–200 ÷ +200
Depending on the value
selected in P176
–10.0 ÷ +10.0 V
–20.0 ÷ +20.0 mA
Default
+100
+10.0 V
Level
ADVANCED
Address
783
Function
Maximum output value obtained when the maximum value of the variable set
in P179 is implemented.
