58.7. State List
Table 139: State list
Number
State
Description
0
ALARM!!!
Alarm tripped
1
STARTING UP
The drive is starting up
2
MAINS LOSS
Mains loss
3
TUNING
The drive is tuning
4
SPEED SEARCHING
Searching for motor speed
5
DCB at START
DC Braking at start
6
DCB at STOP
DC Braking at stop
7
DCB HOLD
DC current for Hold function
8
MANUAL DCB
Manual DC Braking
9
LIMIT WHILE ACCEL.
Current/torque limit while accelerating
10
LIMIT WHILE DECEL.
Current/torque limit while decelerating
11
LIMIT AT ST. SPD
Current/torque limit at constant rpm
12
BRAKING
Braking module startup or deceleration ramp extension
13
RUN AT ST. SPEED
Drive running at speed set point
14
ACCELERATING
Drive running with motor in acceleration stage
15
DECELERATING
Drive running with motor in deceleration stage
16
INVERTER OK
Drive on Stand-by with no alarms tripped
17
FLUXING
Motor fluxing stage
18
FLUXED MOTOR
Motor fluxed
19
FIRE MODE RUN
Constant rpm in Fire Mode
20
FIRE MODE ACC.
Acceleration in Fire Mode
21
FIRE MODE DEC.
Deceleration in Fire Mode
22 INVERTER OK*
Drive on Stand-by with no alarms tripped;
void warranty due to alarm trip in Fire Mode
25
SPARE
Board in Spare mode
27
WAIT NO ENABLE
Waiting for opening ENABLE-A and ENABLE-B commands
28
WAIT NO START
Waiting for opening START command
29
PIDOUT min DISAB
Drive disabled due to PID output < Min.
30
REF min DISABLED
Drive disabled due to REF < Min.
31 IFD WAIT REF.
Drive enabled with IFD control
waiting for reference in order to start
32 IFD WAIT START
Drive enabled with IFD control
waiting for START in order to start
33 DISABLE NO START
When fluxing, the RUN command was not given within the max. time
set in C183. The drive is kept disabled until the RUN command is
given.
