8.7. Temperature Measures from PT100 Menu
This menu displays the temperatures detected in the first four analog channels of the expansion board.
Scaling complies with DIN EN 60751 for PT100: 100 ohm @ 0 °C and 0.385 ohm/°C.
ES847 Expansion Board must be fitted on the equipment.
See also the EXPANSION BOARD CONFIGURATION MENU
M069 PT100 Measure in Channel 1
M069
Range
–500 ÷2600
–50.0 ÷260.0 °C
Active
This measure is active only if programmed from parameter R023.
Address
1719
Function
Temperature detected in analog channel 1.
M070 PT100 Measure in Channel 2
M070
Range
–500 ÷2600
–50.0 ÷260.0 °C
Active
This measure is active only if programmed from parameter R023.
Address
1720
Function
Temperature detected in analog channel 2.
M071 PT100 Measure in Channel 3
M071
Range
–500 ÷2600
–50.0 ÷260.0 °C
Active
This measure is active only if programmed from parameter R023.
Address
1721
Function
Temperature detected in analog channel 3.
M072 PT100 Measure in Channel 4
M072
Range
–500 ÷2600
–50.0 ÷260.0 °C
Active
This measure is active only if programmed from parameter R023.
Address
1722
Function
Temperature detected in analog channel 4.
