Santerno Sinus Penta - List of Parameters C264 to C274

PROGRAMMING GUIDE
SINUS PENTA
391/486
44.4. List of Parameters C264 to C274
Table 120: List of parameters C264 to C274
Parameter FUNCTION User Level
MODBUS
Address
Default Values
C264
Heatsink temperature for fan activation
ADVANCED
1264
50°C
C264a
Fan activation logic selector
AVDANCED
1280
0: Default
C265
Thermal Protection activation for motor 1
BASIC
1265
3: [Fan Shaft]
C266
Trip current for motor 1[Imot%]
ADVANCED
1266
105%
C267
Thermal time constant for motor 1
BASIC
1267
720s
C268
Thermal Protection activation for motor 2
ADVANCED
1268
3: [Fan Shaft]
C269
Trip current for motor 2 [Imot%]
ADVANCED
1269
105%
C270
Thermal time constant for motor 2
ADVANCED
1270
720s
C271
Thermal Protection activation for motor 3
ADVANCED
1272
3: [Fan Shaft]
C272
Pick-up current for motor 3 [Imot%]
ADVANCED
1271
105%
C273
Thermal time constant for motor 3
ADVANCED
1273
720s
C274
PTC Thermal Protection Enable
BASIC
1274
0:[Disabled]
C264 Heatsink Temperature for Fan Activation
C264
Range
0 ÷ 50
0 ÷ 50°C
Default
50
50°C
Level
ADVANCED
Address
1264
Function
This parameter sets the heatsink threshold for the activation of its cooling fans
according to the control logic set in C264a.
This parameter is active only if C264a=0: Default or 2: By Temperature Only.
The real temperature of the heatsink can be displayed in measure parameter M064.
C264a Fan Activation Logic Selector
C264a Range 0 ÷ 2
0: [Default]
1: [Always On]
2: [By Temperature Only]
Default
0
0: [Default]
Level
ADVANCED
Address
1280
Function
This parameter defines the control logic of the heatsink cooling fans.
0: [Default]: The heatsink cooling fans are on whenever the drive is enabled (and
IGBTs are switching)
; when the drive is disabled, fans are off only if the heatsink
temperature drops below C264.
1: [Always On]: Fans are always on.
2: [By Temperature Only]:
Fans are on only if the heatsink temperature is higher than
the value set in C264, regardless of the drive status.
NOTE
Parameters C264 and C264a take effect only for the Penta models where fans are
controlled directly by the drive control board (F
), as displayed on the Product screen in
the PRODUCT MENU. See Table 17 and Table 18.
