PROGRAMMING GUIDE

SINUS PENTA

303/486

35.2. List of Parameters C043 to C135

Table 89: List of parameters C043 to C135

Parameter FUNCTION User Level

MODBUS

Address

DEFAULT

VALUES

C043

Current limit while accelerating

BASIC

1043

150%

C086

ADVANCED

1086

C129

1129

C044

Current limit at constant rpm

BASIC

1044

150%

C087

ADVANCED

1087

C130

1130

C045

Current limit while decelerating

BASIC

1045

See Table 82 and Table 86

C088

ADVANCED

1088

C131

1131

C046

Current limit decrease in field weakening ADVANCED

1046

0: Disabled

C089

1089

C132

1132

C047

Minimum torque ADVANCED

1047

0.0%

C090

1090

C133

1133

C048

Maximum torque

BASIC

1048

120.0%

C091

ADVANCED

1091

C134

1134

C050

Frequency decrease during acceleration

limit

ADVANCED

1050

0: Enabled

C093

1093

C136

1136
