Santerno Sinus Penta - ELECTRICAL SPECIFICATIONS OF THE CONNECTED MOTOR

SINUS PENTA
PROGRAMMING GUIDE
264/486
Table 72: Description of the parameters classified by motor
Parameter Contents
Motor Control 1
Motor Control 2
Motor Control 3
Mains rated voltage
C008


Control algorithm being used
C010 C053 C096
Type of reference being used (speed/torque)
(see Torque Control (VTC and FOC Only)
C011 C054 C097
Availability of the speed feedback from
encoder
C012 C055 C098
Electric ratings of the motor
C015
÷
C025 C058
÷
C068 C101
÷
C111
Max. speed and min. speed required, field
weakening speed, field weakening time
constant, max. speed alarm threshold and
enable
C028
÷
C031 C071
÷
C074 C114
÷
C117
V/f pattern parameters
C013/C032
÷
C038 C056/C075
÷
C081
C099/C118 ÷
C124
Slip compensation activation
C039 C082 C125
Drop in rated current voltage
C040 C083 C126
Fluxing ramp time
C041 C084 C127
The parameters that can be modified depend on the type of control that has been selected.
34.1.1. ELECTRICAL SPECIFICATIONS OF THE CONNECTED
MOTOR
This group of parameters can be divided into two subunits: the first subunit includes the motor ratings, the second
subunit includes the parameters of the equivalent circuit of the asynchronous machine being used.
34.1.2. MOTOR RATINGS
Table 73: Motor ratings
Motor Ratings Motor 1 Motor 2 Motor 3
Rated frequency
C015
C058
C101
Rated rpm
C016
C059
C102
Rated power
C017
C060
C103
Rated current
C018
C061
C104
Rated voltage
C019
C062
C105
No-load power
C020
C063
C106
No-load current
C021
C064
C107
