Santerno Sinus Penta - Table 87: Parameters Depending on the Drive Size and Model - Class 5 T;6 T; 3

PROGRAMMING GUIDE
SINUS PENTA
299/486
Table 87: Parameters depending on the Drive Size and Model - Class 5T/6T / 3
SIZE MODEL
DEF
V/f Pattern
DEF
PREBOOST
[%Vmot]
BOOST @ 5%
fmot and
BOOST
DEF
[%Vmot]
Frequency
for BOOST
DEF
[%fmot]
DEF
Auto BOOST
[%Vmot]
M1
C013
C034
C035/C036
C037
C038
M2
C056
C077
C078/C079
C080
C081
M3
C099
C120
C121/C122
C123
C124
S12/S14
0003
0:CONST
1.0
0
50
1
0004
0:CONST
1.0
0
50
1
0006
0:CONST
1.0
0
50
1
0012
0:CONST
1.0
0
50
1
0018
0:CONST
1.0
0
50
1
S14
0019
0:CONST
1.0
0
50
1
0021
0:CONST
1.0
0
50
1
0022
0:CONST
1.0
0
50
1
0024
0:CONST
1.0
0
50
1
0032
0:CONST
1.0
0
50
1
S22
0042
0:CONST
1.0
0
50
1
0051
0:CONST
1.0
0
50
1
0062
0:CONST
1.0
0
50
1
0069
0:CONST
1.0
0
50
1
S32
0076
0:CONST
1.0
0
50
1
0088
0:CONST
1.0
0
50
1
0131
0:CONST
0.5
0
50
1
0164
0:CONST
0.5
0
50
1
S42
0181
2:FREE
0.2
–20
20
0
0201
2:FREE
0.2
–20
20
0
0218
2:FREE
0.2
–20
20
0
0259
2:FREE
0.2
–20
20
0
S52
0290
2:FREE
0.2
–20
20
0
0314
2:FREE
0.2
–20
20
0
0368
2:FREE
0.2
–20
20
0
0401
2:FREE
0.2
–20
20
0
S65
0457
2:FREE
0.2
–20
20
0
0524
2:FREE
0.2
–20
20
0
0598
2:FREE
0.2
–20
20
0
0748
2:FREE
0.2
–20
20
0
S70
0831
2:FREE
0.2
–20
20
0
S75
0964
2:FREE
0.2
–20
20
0
1130
2:FREE
0.2
–20
20
0
S80
1296
2:FREE
0.2
–20
20
0
S90
1800
2:FREE
0.2
–20
20
0
2076
2:FREE
0.2
–20
20
0
2xS42
0459
2:FREE
0.2
–20
20
0
2xS52
0526
2:FREE
0.2
–20
20
0
0600
2:FREE
0.2
–20
20
0
0750
2:FREE
0.2
–20
20
0
0828
2:FREE
0.2
–20
20
0
3xS52
0960
2:FREE
0.2
–20
20
0
1128
2:FREE
0.2
–20
20
0
