Table 60: List of the programmable measurements in P330 ÷ P331
0
NONE
47
M046 SerPID Ref
1
M000 Speed Ref
48
M047 FbusPID Ref
2
M001 dcm.Spd.Ref
49
M048 SerPID Fbk
3
M002 Ramp Out
50
M049 FbusPID Fbk
4
M003 dcm.Rmp.Out
51
M050 Encoder Ref
5
M004 Motor Speed
52
M051 Freq.In Ref
6
M005 dcm.Mot.Spd
53
M052 Op.Time (low)
7
M006 Mot.Freq.
54
M052 Op.Time (high)
8
M007 Torq.Ref
55
M054 Sply.Time (low)
9
M008 Torq.Demand
56
M054 Sply.Time (high)
10
M009 Torq.Out
57
M056 Digital Out
11
M010 Torq.Ref %
58
M057 Freq.Out
12
M011 Torq.Dem.%
59
M058 Analog Out AO1
13
M012 Torq.Out %
60
M059 Analog Out AO2
14
M013 T.Lim.Ref
61
M060 Analog Out AO3
15
M014 T.Lim.RmpOut
62
M061 Aux. Dig.OUT
16
M015 T.Lim.Ref %
63
M062 Amb.Temp.
17
M016 T.Lim.RmpOut %
64
M036a Aux.Ser. Dig.IN
18
M017 Flux Ref
65
M064 Hts.Temp.
19
M018 PID Ref %
66
M065 OP Counter
20
M019 PID RmpOut %
67
M066 SP Counter
21
M020 PID Fbk %
68
M036b Aux.FBus. Dig.IN
22
M021 PID Err %
69
M022a PID2 Out %
23
M022 PID Out %
70
M069 PT100 Temp.1
24
M023 PID Ref
71
M070 PT100 Temp.2
25
M024 PID Fbk
72
M071 PT100 Temp.3
26
M056a Virtual Dig.Out
73
M072 PT100 Temp.4
27
M026 Mot.Current
74
M028a Energy (low)
28
M027 Out Volt
75
M028a Energy (high)
29
M028 Power Out
76
reserved
30
M029 Vbus-DC
77
M013a Speed Lim Ref
31
M030 V Mains
78
M014a Speed Lim Out
32
M031 Delay.Dig.IN
79
M026a I2t
33
M032 Istant.Dig.IN
80
M039a Analog In XAIN4
34
M033 Term. Dig.IN
81
M039b Analog In XAIN5
35
M034 Ser. Dig.IN
82
M018a PID2 Ref %
36
M035 Fbus. Dig.IN
83
M019a PID2 RmpOut %
37
M036 Aux. Dig.IN
84
M020a PID2 Fbk %
38
M037 Analog In REF
85
reserved
39
M038 Analog In AIN1
86
reserved
40
M039 Analog In AIN2
87
M021a PID2 Err %
41
M040 Ser.SpdRef
88
M023a PID2 Ref
42
M041 dcm.Ser.SpdRef
89
M024a PID2 Fbk
43
M042 Fbus.SpdRef
90
M089 Status
44
M043 dcm.Fbus.SpdRef
91
M090 Alarm
45
M044 Ser.TrqLimRef
92
M056b Timed Flags TFL
46
M045 Fbus.TrqLimRef
93
M027a Power Factor
