54. PROFIDRIVE BOARD CONFIGURATION MENU
54.1. Overview
This menu allows programming the PROFIdrive expansion board. It can be viewed only if the PROFIdrive board is
connected to the control board.
NOTE
Parameters in this menu are Rxxx parameters.
Once changed and saved, they become active only when the drive is next switched on
or when its control board is reset by holding down the RESET key for more than 5 secs.
NOTE
For the correct operation of t
he PROFIdrive board, please refer to the Sinus Penta’s
Motor Drives Accessories – User Manual and to the
PROFIdrive COMMUNICATIONS
BOARD – Installation and Programming Guide.
NOTE
If the PROFIdrive option is present, parameter C149 START Input must be assigned to
value 1: MDI1.
NOTE
If the PROFIdrive option is fitted, alarm A070 is allocated to bit 11 of the Control Word.
A070 trips if parameter R016 is > 0 and bit 11 is set to 0
for a time longer than the time
set in R016. See FIELDBUS CONFIGURATION MENU.
54.2. List of Parameters R025 to R045
Table 131: List of parameters R025 to R045
Parameter FUNCTION User Level
MODBUS
Address
DEFAULT VALUES
R025
Slave address
ENGINEERING
547
1
R026
PZD3 OUT
ENGINEERING
548
1: DIGITAL INPUTS
R027
PZD4 OUT
ENGINEERING
549
0: NOT USED
R028
PZD5 OUT
ENGINEERING
550
0: NOT USED
R029
PZD6 OUT
ENGINEERING
554
0: NOT USED
R030
PZD7 OUT
ENGINEERING
555
0: NOT USED
R031
PZD8 OUT
ENGINEERING
556
0: NOT USED
R032
PZD9 OUT
ENGINEERING
557
0: NOT USED
R033
PZD10 OUT
ENGINEERING
558
0: NOT USED
R034
PZD3 IN
ENGINEERING
559
0: NOT USED
R035
PZD4 IN
ENGINEERING
581
0: NOT USED
R036
PZD5 IN
ENGINEERING
582
0: NOT USED
R037
PZD6 IN
ENGINEERING
583
0: NOT USED
R038
PZD7 IN
ENGINEERING
584
0: NOT USED
R039
PZD8 IN
ENGINEERING
585
0: NOT USED
R040
PZD9 IN
ENGINEERING
586
0: NOT USED
R041
PZD10 IN
ENGINEERING
587
0: NOT USED
R044
Drive Profile Communication Mode
ENGINEERING
520
0: DP V0
R045
Drive Profile Selection
ENGINEERING
521
1: VENDOR SPECIFIC 1
