46.4. Keeping Fluid Level Constant (Example)

Mains

Tank

Fuse

Sensor

Level

4-20mA

Counts

time

Figure 73: Keeping fluid level constant (Example)

Suppose that the maximum level in the tank is to be kept at 50% and that a 4–20mA level probe is used, with an output

of 4mA for the min. level and 20mA for the max. level. The PID reference is sent from keypad, while the probe feedback

is sent to AIN2/PTC analog input, which is configured as follows:

The reference shall be saved from keypad, thus avoiding setting it up again when the drive is shut off.
