Testing Variable A for MDO1 (2,3,4): P273, (P282, P291, P300)
If an analog variable is selected, a logic TEST is performed to obtain a TRUE/FALSE Boolean signal.
Seven different tests are available, that can be performed for selected variable A and its comparing value A:
Table 49: Test functions
GREATER THAN
Selected variable > comparing value
GREATER THAN/EQUAL TO
Selected variable ≥ comparing value
LOWER
Selected variable < comparing value
LOWER THAN/EQUAL TO
Selected variable ≤ comparing value
ABS, GREATER THAN
Absolute value (selected variable) > comparing value
ABS, GREATER THAN/EQUAL TO
Absolute value (selected variable) ≥ comparing value
ABS, LOWER
Absolute value (selected variable) < comparing value
ABS, LOWER THAN/EQUAL TO
Absolute value (selected variable) ≤ comparing value
NOTE
This parameter can be accessed only if the operating mode of the selected digital output
is > 2. Example: MDO1 P270>2.
Testing Variable B for MDO1 (2,3,4): P274, (P283, P292, P301)
If an analog variable is selected, a logic TEST is performed to obtain a TRUE/FALSE Boolean signal.
Seven different tests are available, that can be performed for selected variable B and its comparing value B (see Table
49).
NOTE
This parameter can be accessed only if the operating mode of the selected digital output
is > 2 and < 9. Example: MDO1 2<P270<9.
Reference threshold for P271 (P280, P289, P298) in MDO1: P275, (P284, P293, P302)
This defines the comparing value of Test A with the first selected variable.
NOTE
This parameter can be accessed only if the operating mode of the selected digital output
is > 2. Example: MDO1 P270>2.
Reference threshold for P272 (P281, P290, P299) in MDO2 (3,4): P276, (P285, P294, P303)
This defines the comparing value of Test B with the first selected variable.
NOTE
This parameter can be accessed only if the operating mode of the selected digital output
is > 2. Example: MDO1 P270>2.
