SINUS PENTA
PROGRAMMING GUIDE
58/486
M023 PID Reference after Ramps
M023 Range
±32000
Note: The actual range depends on the max. value and the min. value of
the PID reference set in parameters P245–P246 and on the gain leve
l set in
P257.
Active
Always active.
Address
1673
Function
This is the measure of the reference after the ramps being used for the PID regulator, as M019
but multiplied by the gain level set in P257 (see also the PID PARAMETERS MENU
and the
PID CONFIGURATION MENU
). As for the display/keypad, the unit of measure can be
programmed with parameters P267, P267a in the DISPLAY/KEYPAD menu.
M023a PID2 Reference after Ramps
M023a Range
±32000
Note: The actual range depends on the min. and max. values of the
PID2 reference set in parameters P445-P446 and
on the gain level set
in P457.
Active
This measure is active if enabled from C291a
Address
1737
Function
This is the measure of the reference being used for the PID2 or the 2-zone mode, as M019a
but multiplied by the gain level set in P457 (see also the PID2 PARAMETERS MENU
and the
PID CONFIGURATION MENU
). As for the display/keypad, the unit of measure can be
programmed with parameters P267b, P267c in the DISPLAY/KEYPAD menu.
M024 PID Feedback
M024 Range
±32000
Note: The actual range depends on the max. value and the min. value of
the PID feedback set in parameters P247–P248
and on the gain level set in
P257.
Active
Always active.
Address
1674
Function
This is the measure of the feedback being used for the PID regulator, as M020 but multiplied
by the gain level set in P257 (see also the PID PARAMETERS MENU and the
PID
CONFIGURATION MENU). As for the display/keypad,
the unit of measure can be programmed
with parameters P267, P267a in the DISPLAY/KEYPAD menu.
M024a PID2 Feedback
M024a Range
±32000
Note: The actual range depends on the max. value and the min. value
of the PID2 feedback set in parameters P447–P448
and on the gain
level set in P457.
Active
This measure is active if enabled from C291a
Address
1738
Function
This is the measure of the feedback being used for the PID2 regulator or the 2-zone mode as
M020a but multiplied by the gain level set in P457 (see also the PID2 PARAMETERS MENU
and the PID CONFIGURATION MENU
). As for the display/keypad, the unit of measure can be
programmed with parameters P267b, P267c in the DISPLAY/KEYPAD menu.
