SINUS PENTA
PROGRAMMING GUIDE
252/486
P391 Value of XAIN4 Input Producing Min. Reference
P391 Range
–100 ÷ 100, if P390 = 0
0 ÷ 100, if P390 = 1
–10.0 V ÷ 10.0 V, if P390 = 0: ± 10 V
0.0 V ÷ 10.0V, if P390 = 1: 0 ÷ 10 V
Default
0
0.0V
Level
ADVANCED
Address
991
Function
This parameter selects the value for XAIN4 input signal for minimum reference,
or better the reference set in C028 xP391a (Master mode) or in C047xP391a
(Slave mode). If motor 2 is active, C071 and C090 will be used instead of C028
and C047; if motor 3 is active, the values set in C114 and C133 will be used.
P391a Percentage of Speed_Min/Trq_Min. Producing Min. Reference (Y-axis related to P391)
P391a
Range
0 ÷ 1000
100.0%
Default
1000
100.0%
Level
ADVANCED
Address
704
Function
This parameter represents the min. speed percentage (or the min. torque
percentage for a torque reference) to be used for the minimum reference set with
P391.
P392 Value of XAIN4 Input Producing Max. Reference (X-axis)
P392 Range
–100 ÷ 100, if P390 = 0
0 ÷ 100, if P390 = 3
–10.0 V ÷ 10.0 V, if P390 = 0: ± 10 V
0.0 V ÷ 10.0V, if P390 = 1: 0 ÷ 10 V
Default
100
+10.0V
Level
ADVANCED
Address
992
Function
This parameter selects the value for XAIN4 input signal for maximum reference, or
better the reference set in C029xP392a (Master mode) or in C048xP392a
(Slave
mode). If motor 2 is active, C072 and C091 will be used instead of C029
and
C048; if motor 3 is active, the values set in C115 and C134 will be used.
P392a Percentage of Speed_Max/Trq_Max Producing Max. Reference (Y-axis related to P392)
P392a
Range
0 ÷ 1000
100.0%
Default
1000
100.0%
Level
ADVANCED
Address
710
Function
This parameter represents the max. speed percentage (or the max. torque
percentage for a torque reference) to be used for the maximum
reference set
with P392.
P393 Offset over XAIN4 Input
P393
Range
–1000 ÷ 1000
–10.00 V ÷ +10.00 V
Default
0
0.00 V
Level
ADVANCED
Address
993
Function
This parameter selects the offset correction value of the XAIN4 analog signal that
has been measured.
The value set is added to the signal measured before saturation or conversion; its
unit of measure is the same as the one of the signal selected for XAIN4 ana
log
input.
