PROGRAMMING GUIDE
SINUS PENTA
253/486
P394 Filtering Time over XAIN4 Input
Function
This parameter selects the value of the filter time constant of the first command
applied to the XAIN4 in
put signal when the signal saturation and conversion is
over.
P395 Type of Signal over XAIN5 Input
P395 Range
2 ÷ 4
3: 4 ÷ 20 mA
Function
This parameter selects the type of differential analog signal over terminals
XAIN5+ and XAIN5– in the terminal board.
The signal can be a current signal, a unipolar signal, or a bipolar signal.
2: ±20 mA Bipolar current input between –
20mA and +20mA. The detected signal
is saturated between these two values.
3: 4 ÷ 20 mA Unipolar current input with min. threshold, between +4 mA and
+20mA. The detected signal is saturated between these two values.
Before being saturated, if the detected signal is lower than 4 mA or greater than
20 mA, alarms A069 or A086 trip.
4: 0 ÷ 20 mA
Unipolar current input between +0 mA and +20mA. The detected
signal is saturated between these two values.
P396 Value of XAIN5 Producing Min. Reference (X-axis
P396 Range
+40 ÷ 200, if P395 = 3
–20.0 mA ÷ 20.0 mA, if P395 = 2: ± 20 mA
+4.0mA ÷ 20.0 mA, if P395 = 3: 4 ÷ 20 mA
0.0 mA ÷ 20.0 mA, if P395 = 4: 0 ÷ 20 mA
Function
This parameter selects the value for XAIN5 input signal for minimum reference, or
better the reference set in C028xP396a (Master mode) or in C047xP396a
mode). If motor 2 is active, C071 and C090 will be used instead of C028
and
C047; if motor 3 is active, the values set in C114 and C133 will be used.
P396a Percentage of Speed_Min/Trq_Min Producing Min. Reference (Y-axis related to P396)
Function
This parameter represents the min. speed percentage (or the min. torque
percentage for a torque reference) to be used for the minimum reference set with
P396.
