SINUS PENTA
PROGRAMMING GUIDE
254/486
P397 Value of XAIN5 Input Producing Max. Reference (X-axis)
P397
Range
–200 ÷ 200, if P395 = 2
+40 ÷ 200, if P395 = 3
0 ÷ 200, if P395 = 4
–20.0 mA ÷ 20.0 mA, if P395= 2: ± 20 mA
+4.0mA ÷ 20.0 mA, if P395= 3: 4 ÷ 20 mA
0.0 mA ÷ 20.0 mA, if P395= 4: 0 ÷ 20 mA
Default
200
+20.0mA
Level
ADVANCED
Address
997
Function
This parameter selects the value for XAIN5 input signal for maximum reference, or
better the reference set in C029xP397a (Master mode) or in C048xP397a
(Slave
mode). If motor 2 is active, C072 and C091 will be used instead of C029
and
C048; if motor 3 is active, the values set in C115 and C134 will be used.
P397a Percentage of Speed_Max/Trq_Max Producing Max. Reference (Y-axis related to P397)
P397a
Range
0 ÷ 1000
100.0%
Default
1000
100.0%
Level
ADVANCED
Address
712
Function
This parameter represents the max. speed percentage (or the max. torque
percentage for a tor
que reference) to be used for the maximum reference set
with P397.
P398 Offset over XAIN5 Input
P398
Range
–2000 ÷ 2000
– 20.00 mA ÷ +20.00 mA
Default
0
0 mA
Level
ADVANCED
Address
998
Function
This parameter selects the offset correction value of XAIN5 analog signal that has
been measured.
The value set is added to the signal measured before saturation or conversion; its
unit of measure is the same as the one of the signal selected for XAIN5 analog
input.
P399 Filtering Time over XAIN5 Input
P399
Range
0 ÷ +65000
0 ÷ +65000ms
Default
100
100 ms
Level
ADVANCED
Address
999
Function
This parameter selects the value of the filter time constant of the first command
applied to XAIN5 input signal when the signal saturation and conversion is over.
