Santerno Sinus Penta - Page 169

PROGRAMMING GUIDE
SINUS PENTA
169/486
P228 Timers Assigned to Outputs MDO1
÷
4
P228 Range
[ 0; 0; 0; 0 ] ÷ [ 5; 5; 5; 5 ]
0: No timer assigned
1 ÷ 5: T1 ÷ T5
Default [ 0; 0; 0; 0 ] 0: No timer assigned
Level
ENGINEERING
Address
828
Function
The digital outputs may be assigned to any of the five timers and the same timer may
be assigned to multiple outputs.
Select “zero” to avoid delaying the digital outputs.
Setting via serial link: see coding in P226.
P229 Timers Assigned to Virtual Outputs MPL 1
÷
4
P229 Range
[ 0; 0; 0; 0 ] ÷ [ 5; 5; 5; 5 ]
0: No timer assigned
1 ÷ 5: T1 ÷ T5
Default
[ 0; 0; 0; 0 ]
0: No timer assigned
Level
ENGINEERING
Address
829
Function
The virtual digital outputs may be assigned to any of the five timers and the same
timer may be assigned to multiple outputs.
Select “zero” to avoid delaying the virtual digital outputs.
Setting via serial link: see coding in P226.
