SINUS PENTA
PROGRAMMING GUIDE
64/486
M049 PID Feedback from Fieldbus
M049 Range
±10000
±100.00 %
Note: The actual range depends on the min.
value and the max. value of the
PID feedback set in parameters:
P247P248
Active
Always active.
Address
1699
Function This is the measure of the PID feedback set by the fieldbus and expressed as a percentage.
M050 Encoder Reference
M050
Range
± 32000
± 32000 rpm.
Active
Always active.
Address
1700
Function
Reading of the encoder set as a reference source (see the
ENCODER/FREQUENCY INPUTS
MENU and the CONTROL METHOD MENU).
M051 Frequency Input Reference
M051 Range
1000 ÷ 10000
10000 ÷ 100000 Hz.
Note
: The actual range depends on the frequency min. value
and max. value set in P071-P072.
Active
Always active.
Address
1701
Function
Frequency readout in the digital input set as a reference source (see the
ENCODER/FREQUENCY INPUTS MENU and the CONTROL METHOD MENU).
M051a RMS Input from AIN1 and AIN2
M051a
Range
0 ÷ 32000
0.00 ÷ 32.00 V
Active
This measurement is active only if one of parameters among C288, C289 or C290 = 13: Vout
measured.
Also, P055, P060 = 0: ±10V.
Address
3374
Function
RMS voltage obtained from instantaneous values of AIN1 and AIN2 if they are two
sinusoidal
voltage values having equal amplitude and frequency phase displacement of 120˚.
