PROGRAMMING GUIDE
SINUS PENTA
453/486
Alarm
Alarm Message
Description
A092
SW Version KO
Control board failure
A093
Bypass Circuit Open
By-Pass relay open
A094
HeatSink Overheated
IGBT heatsink temperature too high
A095
Illegal Drive Profile Board
Drive Profile board not correctly configured
A096
Fan Fault
Fault of the cooling fans
A097
Motor Not Connected
Motor not connected
A098
Illegal Motor Selected
Illegal motor selected via MDI
A099
2nd Sensor Fault
Fault of fan sensor 2
A100
MDI6 Illegal Configuration
Function programmed for MDI6 along with frequency input A
A101
MDI8 Illegal Configuration
Function programmed for MDI8 along with frequency input B
A102
REF > 20mA
REF Current input (4÷20mA or 0÷20mA) greater than 20mA
A103
AIN1 > 20mA
AIN1 Current input (4÷20mA or 0÷20mA) greater than 20mA
A104
AIN2 > 20mA
AIN2 Current input (4÷20mA or 0÷20mA) greater than 20mA
A105
PT100 Channel 1 Fault
Hardware address out of measure range of the drive
A106
PT100 Channel 2 Fault
Hardware address out of measure range of the drive
A107
PT100 Channel 3 Fault
Hardware address out of measure range of the drive
A108
PT100 Channel 4 Fault
Hardware address out of measure range of the drive
A109
Amb.Overtemp.
Ambient overtemperature
A110
Fieldbus Board Fault
Fault occurring in the Fieldbus board
A111 ÷ A120
…
Control board failure
A129
No Output Phase
Output phase loss
A140
Torque Off not Safe
Malfunctioning of ENABLE-A and ENABLE-B inputs for STO function
A141
Illegal Hardware
SW version incompatible with the drive hardware
A001
÷
A032, A043, A049, A063, A071, A078, A088, A092, A111
÷
A120 Control Board Failure
A001 ÷ A032
A043
A049
A063
A071
A078
A088
A092
A111
÷
A120
Description
Control board failure
Event
There may be several causes: the board autodiagnostics file constantly checks its
operating conditions.
Possible
cause
• Strong electromagnetic disturbance or radiated interference.
• Possible failure of the microcontroller or other circuits on the control board.
Solution
1. Reset the alarm: send a RESET command.
2. If the alarm persists, please contact ELETTRONICA SANTERNO’s Customer
Service.
A033 Texas Software KO
A033 Description Incompatible Software Texas version
Event
When switched on, DSP Motorola detected an incompatible version of the software
downloaded to Flash Texas (software version incompatible with Motorola).
Possible
cause
The wrong software was downloaded.
Solution
1. Download the correct DSP Texas software version.
2. If the alarm persists, please contact ELETTRONICA SANTERNO’s Customer
Service.
