SINUS PENTA
PROGRAMMING GUIDE
118/486
P061a Percentage of Speed_Min/Trq_Min Producing Min. Reference (Y-axis related to P061)
P061a
Range
0 ÷ 1000
100.0%
Default
1000
100.0%
Level
ADVANCED
Address
679
Function
This parameter represents the min. speed percentage (or the min. torque
percentage for a torque reference) to be used for the minimum reference set with
P061.
P062 Value of AIN2 Input Producing Max. Reference (X-axis)
P062 Range
–100 ÷ 100, if P060 = 0
–200 ÷ 200, if P060 = 1
+40 ÷ 200, if P060 = 2
0 ÷ 100, if P060 = 3
0 ÷ 200, if P060= 4
–10.0 V ÷ 10.0 V, if P060= 0: ± 10 V
–20.0 mA ÷ 20.0 mA, if P060 = 1: ± 20 mA
+4.0mA ÷ 20.0 mA, if P060 = 2: 4 ÷ 20 mA
0.0 V ÷ 10.0V, if P060 = 3: 0 ÷ 10 V
0.0 mA ÷ 20.0 mA, if P060 = 4: 0 ÷ 20 mA
Default
200
+20.0 mA
Level
ADVANCED
Address
662
Function
This parameter selects the value for AIN2 input signal for maximum reference, or
better the reference set in C029xP062a (Master mode) or in C048xP062a
(Slave
mode). If motor 2 is active, C072 and C091 will be used instead of C029 and C048
; if
motor 3 is active, the values set in C115 and C134 will be used.
P062a Percentage of Speed_Min/Trq_Min Producing Max. Reference (Y-axis related to P062)
P062a
Range
0 ÷ 1000
100.0%
Default
1000
100.0%
Level
ADVANCED
Address
701
Function
This parameter represents the max. speed percentage (or the min. torque percentage
for a torque reference) to be used for the maximum reference set with P062.
P063 Offset over AIN2 Input
P063 Range
–2000 ÷ 2000
–10.00 V ÷ +10.00 V, if P060 = 0 o 3
– 20.00 mA ÷ +20,00 mA , if P060 = 1,2,4
Default
0
0 V
Level
ADVANCED
Address
663
Function
This parameter selects the offset correction value of AIN2 analog signal that has
been measured.
The value set is added to the signal measured before saturation or conversion; its
unit of measure is the same as the one of the signal selected for AIN2 analog input.
