Santerno Sinus Penta - Page 218

SINUS PENTA
PROGRAMMING GUIDE
218/486
P308 XMDO2: Signal Selection
P308
Range
0 ÷ 79
See Table 48
Default
0
D0: Disable
Level
ENGINEERING
Address
908
Function
Selects the digital signal used to calculate the value of XMDO2 digital output.
It selects an analog variable used to calculate the value of XMDO2
digital input if
one of the “analog” operating modes is selected.
Digital signals and analog variables are detailed in Table 48.
P309 XMDO2: Output Logic Level
P309 Range
0–1
0: FALSE
1: TRUE
Default
1
1: TRUE
Level
ENGINEERING
Address
909
Function
XMDO2 digital output logic function to apply a logic reversal (negation) to the
calcul
ated output signal: (0) FALSE = a logic negation is applied; (1) TRUE = no
negation is applied.
P310 XMDO3: Signal Selection
P310
Range
0 ÷ 79
See Table 48
Default
0
D0: Disable
Level
ENGINEERING
Address
910
Function
Selects the digital signal used to calculate the value of XMDO3 digital output.
It selects an analog variable used to calculate the value of XMDO3
digital input if
one of the “analog” operating modes is selected.
Digital signals and analog variables are detailed in Table 48.
P311 XMDO3: Output Logic Level
P311 Range
0–1
0: FALSE
1: TRUE
Default
1
1: TRUE
Level
ENGINEERING
Address
911
Function
XMDO3 digital output logic function to apply a logic reversal (negation) to the
calculated output signal: (0) FALSE = a logic negation is applied; (1) TRUE = no
negation is applied.
