Santerno Sinus Penta - Page 220

SINUS PENTA
PROGRAMMING GUIDE
220/486
P316 XMDO6: Signal Selection
P316
Range
0 ÷ 59
See Table 48
Default
0
D0: Disable
Level
ENGINEERING
Address
916
Function
Selects the digital signal used to calculate the value of XMDO6 digital output.
It selects an analog variable used to calculate the value of XMDO6
digital input if
one of the “analog” operating modes is selected.
Digital signals and analog variables are detailed in Table 48.
P317 XMDO6: Output Logic Level
P317 Range
0–1
0: FALSE
1: TRUE
Default
1
1: TRUE
Level
ENGINEERING
Address
917
Function
XMDO6 digital output logic function to apply a logic reversal (negation) to the
calculated output signal: (0) FALSE = a logic negation is applied; (1) TRUE = no
negation is applied.
