Santerno Sinus Penta - Page 223

PROGRAMMING GUIDE
SINUS PENTA
223/486
P324 Channel 3: Measure Mode
P324 Range
0 ÷ 1
0: no input
1: val PT100
Default
0
0: no input
Level
ADVANCED
Address
924
Function
This parameter selects the type of analog signal available in terminals 31–32 in
ES847 expansion board.
0: no signal is used. The P parameter relating to the analog input disappears.
1: val PT100. The acquired signal is transformed into degrees centigrade.
See Measure M071.
P325 Channel 3: Measure Offset
P325
Range
–30000 ÷ 30000
–300.00 ÷ 300.00
Default
0
0.0 °C
Level
ADVANCED
Address
925
Function
Value of the measure offset for channel 3: an offset can be applied to the
measure to correct possible errors.
P326 Channel 4: Measure Mode
P326 Range
0 ÷ 1
0: no input
1: val PT100
Default
0
0: no input
Level
ADVANCED
Address
926
Function
This parameter selects the type of analog signal available in terminals 33–34 in
ES847 expansion board.
0: no signal is used. The P parameter relating to the analog input disappears.
1: val PT100. The acquired signal is transformed into degrees centigrade.
See Measure M072.
P327 Channel 4: Measure Offset
P327
Range
–30000 ÷ 30000
–300.00 ÷ 300.00
Default
0
0.0 °C
Level
ADVANCED
Address
927
Function
Value of the measure offset for channel 4: an offset can be applied to the
measure to correct possible errors.
