PROGRAMMING GUIDE
SINUS PENTA
231/486
Function applied to the result of f(A,B) C for MPL1: P357b, (P366b, P375b, P384b)
Once the Boolean signal resulting from f(A,B) is obtained, an additional logic function can be applied to obtain the
output TRUE//FALSE Boolean signal.
If parameter P357a is disabled, the output of f(A,B) goes directly to the corresponding digital output; if parameter P357a
is enabled, the output of the output of f(A,B) becomes one of the two inputs of the second programmed block.
The user can choose one of the six Boolean tests above for the first variable—f(A,B)—and for the second variable (C).
Logic applied to MPL1 (2, 3,4): P358, (P367, P376, P385)
The logic of the Boolean signal can be reversed at the end of the processing chain.
The user can choose whether the logic level of the digital output is POSITIVE or NEGATIVE.
(0) FALSE = a logic negation is applied (NEGATIVE logic).
(1) TRUE = no negation is applied (POSITIVE logic).
NOTE
This parameter can be accessed only if the operating mode of the selected digital output is
other than zero. Example: MPL1 P350≠0
NOTE Please refer to Programmable Operating Modes (Diagrams) relating to the digital outputs.
