C030a (C073a, C116a) Field Weakening Time Constant
C030a (mot. n.1)
C073a (mot. n.2)
C116a (mot. n.3)
Range
0 ÷ 32000 0: Disabled ÷ 32000ms
Default
500
500ms
Level
ENGINEERING
Address
1137, 1138, 1139
Control
VTC and FOC
Function
With C030a (C073a, C116a)=other than 0: Disabled, the motor field weakening
follows a law optimizing the output voltage based on the available DC voltage
(“automatic” field weakening).
This parameter defines the trip rate of the automatic field weakening regulator.
For more details, see Field Weakening (VTC and FOC Only).
C031 (C074, C117) Max. Speed Alarm
C031 (Motor 1)
C074 (Motor 2)
C117 (Motor 3)
Range
0 ÷ 32000
0: (Disabled) ÷ 32000 rpm
Default
0
0: Disabled
Level
ADVANCED
Address
1031, 1074, 1117
Function
If it is not set to zero, this parameter determines the speed value to be entered for the
maximum speed alarm (A076).
C032 (C075, C118) Reduction in Quadratic Torque Curve
C032 (Motor 1)
C075 (Motor 2)
C118 (Motor 3)
Range
0 ÷ 1000
0 ÷ 100.0%
Default
300
30.0%
Level
ADVANCED
Address
1032, 1075, 1118
Control
IFD
Function
If the V/f curve pattern C013 (C056, C099) = Quadratic, this parameter defines the
maximum voltage reduction in terms of theoretical
V/f pattern, which is
implemented at the frequency programmed in C033 (C076, C119).
C033 (C076, C119) Max. Reduction Frequency for Quadratic Torque Pattern
C033 (Motor 1)
C076 (Motor 2)
C119 (Motor 3)
Range
1 ÷ 100
1 ÷ 100%
Default
20
20%
Level
ADVANCED
Address
1033, 1076, 1119
Control
IFD
Function
If the V/f curve pattern C013 (C056, C099) = Quadratic, this parameter defines
the frequency implementing the max. torque reduction in terms of theoretical
V/f
pattern set in C032 (C075, C120).
