Santerno Sinus Penta - Page 376

SINUS PENTA
PROGRAMMING GUIDE
376/486
C230 Voltage Level of DC Bus in Power Down
C230 Range
250 ÷ 450 for Class 2T
400 ÷ 800 for Class 4T
500 ÷ 960 for Class 5T
600
÷
1150 for Class 6T
250 ÷ 450 V for Class 2T
400 ÷ 800 V for Class 4T
500 ÷ 960 V for Class 5T
600
÷
1150 V for Class 6T
Default
339 for Class 2T
679 for Class 4T (380÷ 480V)
707 for Class 4T (481÷ 500V)
813 for Class 5T
976 for Class 6T
339 V for Class 2T
679 V for Class 4T (380÷ 480V)
707 V for Class 4T (481÷ 500V)
813 V for Class 5T
976 V for Class 6T
Level
ENGINEERING
Address
1230
Function
Determines the reference value for DC bus voltage in case of automatic
deceleration in Power Down; C225 = Yes V.
C231 PI Proportional Constant for Automatic Deceleration
C231
Range
0 ÷ 32000
0.000 ÷ 32.000
Default
50
0.050
Level
ENGINEERING
Address
1231
Function
Proportional coefficient used in PI regulator controlling automatic deceleration in
case of Power Down; C225 =Yes V.
C232 PI Integral Time for Automatic Deceleration
C232 Range
1 ÷ 32000
0.001 ÷ 31.999 sec
32000 = Disabled
Default
500
0.5 sec
Level
ENGINEERING
Address
1232
Function
Integral time used in PI regulator controlling automatic deceleration in case of
Power Down; C225 =Yes V.
