PROGRAMMING GUIDE

SINUS PENTA

383/486

C250 MDI for Speed Searching Enable

C250 Range

0 ÷ 16

0 ÷ 24 if ES847 or ES870

fitted

0 → Inactive

1 ÷ 8 → MDI1 ÷ MDI8

9 ÷ 12 → MPL1 ÷ MPL4

13 ÷ 16 → TFL1 ÷ TFL4

17 ÷ 24 → XMDI1 ÷ XMDI8

Default

0: Inactive

Level

ENGINEERING

Address

1250

Control

IFD, VTC

Function

If set to Inactive, it will take no effect. Otherwise, Speed Searching activates only if

the preset input is active.
