PROGRAMMING GUIDE
SINUS PENTA
39/486
Parameters included in the Start-Up menu:
Parameter
Description
Visibility
C008
Rated mains voltage
C010
Type of control algorithm
C012
Speed feedback from encoder
[only if FOC is active]
C013 Type of V/f pattern [only if IFD is active]
C015
Rated motor frequency
C016
Rated motor rpm
C017
Rated motor power
C018
Rated motor current
C019
Rated motor voltage
C021
No-load current of the motor
[only if FOC is active]
C028
Min. motor speed
C029
Max. motor speed
C034
Voltage preboost
[only if IFD is active]
P009
Acceleration ramp time
P010 Deceleration ramp time
C043
Current limit while accelerating [only if IFD is active]
C044
Current limit at constant rpm [only if IFD is active]
C045
Current limit while decelerating [only if IFD is active]
C048
Torque limit [only if VTC/FOC are active]
C189
Encoder operating mode [only if FOC is active]
C190
Encoder A pls/rev
[only if FOC is active]
C191
Encoder B pls/rev
[only if FOC is active]
I073
Autotune selection
[only if VTC/FOC are active]
I074
Motor tuning selection
[only if VTC/FOC are active]
C265
Motor thermal protection
C267
Motor thermal time constant [only if protection is active]
After setting the last parameter and moving the cursor forward, the following page will appear:
P
r
e
s
s
U
P
A
R
R
O
W
t
o
q
u
i
t
D
O
W
N
A
R
R
O
W
t
o
c
o
n
t
i
n
u
e
Press ▲ to quit the Start-up menu. The default page of the system will be displayed.
