PROGRAMMING GUIDE

SINUS PENTA

421/486

C336 (C343, C350, C357) Days of the Week of the Activation of the Timed Flag TFL1 (TFL2, TFL3, TFL4)

C336

C343

C350

C357

Range

0000000b ÷1111111b

binary

0 ÷ 127

Default

Level

ADVANCED

Address

277(284, 291, 298)

Function

Sets the second of deactivation of the timed flag TFL1 (TFL2, TFL3, TFL4).

Every bit corresponds to a day of the week: bit 1 corresponds to Monday, bi

t 7

corresponds to Sunday. Example:

1111100: flag TLF1

will activate every day of the week but Saturday and

Sunday.

0000000: the flag will never activate.

1111111: the flag will activate every day.
