SINUS PENTA
PROGRAMMING GUIDE
424/486
Error Messages
If a message error is detected, the inverter will send a message to the master:
The error code meaning is the following:
0x01 ILLEGAL FUNCTION
The function sent by the Master is different from 0x03 (Read Holding
Registers) and 0x10 (Preset Multiple Registers).
The Master wrote to or read from an illegal address.
0x03 ILLEGAL DATA VALUE
The numerical value the Master tried to write is not included in the correct
range.
0x06 DEVICE BUSY
The drive refused the Master writing attempt (e.g. because it is running and a
Cxxx parameter is activated).
0x07 ANOTHER USER WRITING
Other users are writing to the selected parameter when the Master is trying to
write to this parameter (e.g. display/keypad in editing mode or
Upload/Download to/from keypad).
0x09 BAD ACCESS LEVEL
The parameter the Master is trying to write to is not included in the selected
User Level (e.g. it is trying to write an ADVANCED parameter when the
BASIC user level is selected).
