Santerno Sinus Penta - Page 467

PROGRAMMING GUIDE
SINUS PENTA
467/486
A096 Fan Fault
A096 Description Fan alarm.
Event
Power heatsink overheated with fan locked or disconnected or faulty (see also A094
and A099).
Possible
cause
Fan locked or disconnected or faulty.
Solution
Replace fan.
A097 Motor Cables KO
A097
Description
Motor not connected.
Event
This protection trips during autotune or DC Brake if the motor is not connected to the
drive or if its current value is not compatible with the drive size.
Possible
cause
• One cable of the motor is disconnected.
• The motor size is too small if compared to the drive size.
Solution
1. Check that motor cables are properly connected to terminals U, V, W.
2. Check the motor parameters; perform autotune procedure again (VTC and FOC
controls).
A098 Illegal Motor
A098 Description
A disabled motor has been selected.
Event
• Motor 2 is enabled, but only one motor can be enabled: C009=1 (see the MOTOR
CONFIGURATION MENU).
• Motor 3 is enabled, but only 1 or 2 motors can be enabled: C009=1 or 2 (see the
MOTOR CONFIGURATION MENU).
Possible
cause
• Incorrect setting in parameter C009.
•
Incorrect setting of the digital input parameters enabling the selection functions for
motor 2 (C173) and/or motor 3 (C174).
Solution
1. Check and enter the correct value for C009.
2. Check and enter the correct value for C173, C174.
3. Check the status of the digital commands for terminals C173 and C174. If remote
command sources are selected, check the status of the commands that have been
sent.
A099 Sensor 2 Fault
A099 Description
Sensor 2 fault.
Event
Power heatsink overheated with cooling fan off (see also A094 and A096).
Possible
cause
Failure in temperature control device and/or cooling system.
Solution
Please contact ELETTRONICA SANTERNO’s Customer Service.
A100 MDI6 Illegal Configuration
A100 Description Function programmed to MDI6 and frequency input A as well.
Event
MDI6 terminal is programmed with a digital function command and as frequency input
A.
Possible
cause
Incorrect programming of a command function for MDI6, because frequency input A is
already set in parameter C189 (FinA) (see the DIGITAL INPUTS MENU
and the
ENCODER/FREQUENCY INPUTS MENU).
Solution
Check and adjust programming of the digital input functions and of parameter C189.
