PAR.-Meaning Default Values
Modified
values
PAR.-Meaning Default Values
Modified
values
R00x-R01x Serial Link
R001-com_slaveaddr
1
R002-com_answdelay
5 ms
R003-sc0_baudrate
38400 bps
R004-com_4time_delay
2 ms
R005-ser_wdg_time
0.0 s
R006-parity sc0
1: No, 2 Stop Bit
R008-cm1_slaveaddr
1
R009-cm1_answdelay
5 ms
R010-sc1_baudrate
38400 bps
R011-cm1_4time_delay
2 ms
R012-sr1_wdg_time
0.0 s
R013-parity sc1
1: No, 2 Stop Bit
R01x Fieldbus Configuration
R016-fbs_wdg_time
0 ms
R017a-AO1_fb_sel
0: No
R017b-AO2_fb_sel
0: No
R017c-AO3_fb_sel
0: No
R018-fb_Address
0
R018a-fb_BaudRate
125k
R018b-fb_TypeWD
0 → bit 15 to 1
R02x Expansion Board Settings
R021-Data Logger Setting
1: NO
R023- I/O Board setting
0:None
R02x-R04x PROFIdrive Settings
R025-SlaveAddr
1
R026-PZD3_O_Addr
1: Digital Inputs
R027-PZD4_O_Addr
0: not used
R028-PZD5_O_Addr
0: not used
R029-PZD6_O_Addr
0: not used
R030-PZD7_O_Addr
0: not used
R031-PZD8_O_Addr
0: not used
R032-PZD9_O_Addr
0: not used
R033-PZD10_O_Addr
0: not used
R034-PZD3_I_Addr
0: not used
R035-PZD4_I_Addr
0: not used
R036-PZD5_I_Addr
0: not used
R037-PZD6_I_Addr
0: not used
R038-PZD7_I_Addr
0: not used
R039-PZD8_I_Addr
0: not used
R040-PZD9_I_Addr
0: not used
R041-PZD3_I_Addr
0: not used
R044-DP com.mode
0: DP V0
R045-DP sel.
1: VENDOR SPECIFIC
1
R05x Daylight Saving Time
R050-DSTOn WDMM
5703
R051-DSTOn HHMM
200
R052-DSTOff WDMM
5710
R053-DSTOff HHMM
200
R11x Data Logger
R115-PIN card SIM “0000”
R116-Preset
Connections
0: Disable
Key:
[*] Parameter depending on the current size.
[**] Parameter depending on the voltage class.
