M5: Measurement
7.5 Setting zeros, workpiece measuring and tool measuring
Extended Functions
456 Function Manual, 03/2013, 6FC5397-1BP40-3BA1
The following is applicable if the variable $AC_MEAS_FINE_TRANS is not described:
● The compensation value is entered in the coarse offset and transformed in the time
frame. There can also be a fine portion in the translation by virtue of the transformations.
● If the following machine data is not preset to 1:
MD18600 $MN_MM_FRAME_FINE_TRANS
The compensation is always entered in the course offset.
Calculated frame
When a workpiece is measured, the calculated frame is entered in the specified frame.
Type System variable Meaning
INT $AC_MEAS_FRAME_SELECT Frame selection during tool measurement
The variable $AC_MEAS_FRAME_SELECT can assume the following values:
Value Meaning
0 $P_SETFRAME Active system frame
1 $P_PARTFRAME Active system frame
2 $P_EXTFRAME Active system frame
10..25 $P_CHBFRAME[0..15] Active channel-specific basic frames
50..65 $P_NCBFRAME[0..15] active NCU-global basic frames
100..199 $P_IFRAME The calculation is done using the active settable
frame, if the corresponding frame is selected. If
the selected frame is not active, the corresponding
data management frame is included in the
calculation.
500 $P_TOOLFRAME Active system frame
501 $P_WPFRAME Active system frame
502 $P_TRAFRAME Active system frame
503 $P_PFRAME Active current programmable frame
504 $P_CYCFRAME Active system frame
505 $P_RELFRAME (workpiece
coordinate system)
Active system frame
506 $P_RELFRAME (SZS) Active system frame
1010..1025 $P_CHBFRAME[0..15] active channel specification Basic frames with
active G500
1050..1065 $P_NCBFRAME[0..15] active NCU-global Basic frames with active G500
2000 $P_SETFR System frame in data management
2001 $P_PARTFR System frame in data management
2002 $P_EXTFR System frame in data management
2010..2025 $P_CHBFR[0..15] Channel-specific basic frames in data
management
2050..2065 $P_NCBFR[0..15] NCU-global basic frame in data management
