Debug support (DBG) RM0033
1326/1381 RM0033 Rev 9
32.6 ID codes and locking mechanism
There are several ID codes inside the STM32F20x and STM32F21x MCUs. ST strongly
recommends tools designers to lock their debuggers using the MCU DEVICE ID code
located in the external PPB memory map at address 0xE0042000.
32.6.1 MCU device ID code
The STM32F20x and STM32F21x MCUs integrate an MCU ID code. This ID identifies the
ST MCU part-number and the die revision. It is part of the DBG_MCU component and is
mapped on the external PPB bus (see Section 32.16). This code is accessible using the
JTAG debug port (four to five pins) or the SW debug port (two pins) or by the user software.
It is even accessible while the MCU is under system reset.
Only the DEV_ID[11:0] should be used for identification by the debugger/programmer tools.
DBGMCU_IDCODE
Address: 0xE004 2000
Only 32-bits access supported. Read-only.
32.6.2 Boundary scan TAP
JTAG ID code
The TAP of the STM32F20x and STM32F21x BSC (boundary scan) integrates a JTAG ID
code equal to 0x0BA00477.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
REV_ID[15:0]
rrrrrr r r r r rrrrrr
1514131211109876543210
Reserved
DEV_ID[11:0]
rrrrrrrrrrrr
Bits 31:16 REV_ID[15:0] Revision identifier
This field indicates the revision of the device:
0x1000 = Revision A
0x1001 = Revision Z
0x2000 = Revision B
0x2001 = Revision Y
0x2003 = Revision X
0x2007 = Revision 1
0x200F = Revision V
0x201F = Revision 2 or 3
0x203F = Revision 4 or 5
Bits 15:12 Reserved, must be kept at reset value.
Bits 11:0 DEV_ID[11:0]: Device identifier
The device ID is 0x411
