Interrupts and events RM0033
168/1381 RM0033 Rev 9
8.2 External interrupt/event controller (EXTI)
The external interrupt/event controller consists of up to 23 edge detectors for generating
event/interrupt requests. Each input line can be independently configured to select the type
(interrupt or event) and the corresponding trigger event (rising or falling or both). Each line
can also masked independently. A pending register maintains the status line of the interrupt
requests
8.2.1 EXTI main features
The main features of the EXTI controller are the following:
• independent trigger and mask on each interrupt/event line
• dedicated status bit for each interrupt line
• generation of up to 23 software event/interrupt requests
• detection of external signals with a pulse width lower than the APB2 clock period. Refer
to the electrical characteristics section of the STM32F20x and STM32F21x datasheets
for details on this parameter.
71 78 settable USART6 USART6 global interrupt 0x0000_015C
72 79 settable I2C3_EV I
2
C3 event interrupt 0x0000_0160
73 80 settable I2C3_ER I
2
C3 error interrupt 0x0000_0164
74 81 settable
OTG_HS_EP1_OU
T
USB On The Go HS End Point 1
Out global interrupt
0x0000_0168
75 82 settable OTG_HS_EP1_IN
USB On The Go HS End Point 1 In
global interrupt
0x0000_016C
76 83 settable OTG_HS_WKUP
USB On The Go HS Wakeup
through EXTI interrupt
0x0000_0170
77 84 settable OTG_HS USB On The Go HS global interrupt 0x0000_0174
78 85 settable DCMI DCMI global interrupt 0x0000_0178
79 86 settable CRYP CRYP crypto global interrupt 0x0000_017C
80 87 settable HASH_RNG Hash and Rng global interrupt 0x0000_0180
Table 20. Vector table (continued)
Position
Priority
Type of
priority
Acronym Description Address
